| Place of Origin: | China |
| Brand Name: | Bai Zhuang |
| Certification: | RoHS,Reach |
| Model Number: | BZ-5518-3-X |
High Transparent and Yellow Resistant PU Potting Compound with Rapid Curing
BZ-5518-3-X-1 is a high-transparency, yellow-resistant polyurethane potting adhesive specifically formulated for decorative wall coverings and printed materials. The product complies with the requirements of ROHS, REACH, and California 65. The cured adhesive forms a three-dimensional crystal-like surface with optimal hardness, remaining flexible and non-brittle even at low temperatures. It maintains its color for three years without yellowing, ensuring both aesthetic appeal and durability.
|
Parameters |
Hardener BZ-5518-X-3-1 A |
Resin BZ-5518-X-3-1 B |
|
|
Before curing |
Appearance |
Clear liquid |
Clear liquid |
|
Viscosity(mPa·s.25℃) |
5-55 |
200-480 |
|
|
Initial mixed viscosity(mPa·s.25℃) |
120-280 |
||
|
Density(g/cm³.25℃) |
1.05±0.05 |
1.01±0.05 |
|
|
Mixing&Curing
|
Mix ratio(by weight) |
A:B=1:3 |
|
|
Pot life 130±30g(min.25℃) |
9-17min |
||
|
Curing condition |
Room temperature curing |
||
|
Surface drying time 30g(min.25℃) |
15-30min |
||
|
Curing time 30g(min.25℃) |
30-40min |
||
|
Curing time 30g(Heated) |
60℃ heated ≤12min |
||
|
After curing
|
Hardness (Shore A) |
62±10 |
|
|
Temperature resistance(℃) |
-40~85℃ |
||
|
Water absorption(24H) |
≤1.0% |
||
|
Surface resistivity (Ω/sq) |
≥1.0×1012 |
||
|
Volume resistivity (Ω.cm) |
≥1.0×1012 |
||
|
Tensile strength(MPa) |
≤2 |
||
|
Elongation at break(%) |
≥40% |
||
|
Dielectric constant(at 50Hz) |
≥8 |
||
|
Breakdown voltage(kV/mm)
|
≥14 |
||
1. Decorative wallpaper: High transparency and accelerated curing properties, achieving over 300% higher production efficiency than epoxy resin; soft and long-lasting smooth surface without peeling after curing.
2. Printing materials: same as above;
Pre-potting Preparation: Calibrate scales, prepare potting tools, cleaning tools, check machine settings, check vacuum pump force, etc.
Product Pre-treatment: Place product on a level surface or fixture. Remove dust, clean, degrease, and dry if necessary.
Accurate Proportioning: Manual operation requires precise mixing according to the specified ratio and recording. Machine potting requires calibrated ratios and first-article confirmation is recommended.
Mixing & Stirring: Manual operation requires thorough stirring or using electric stirrers to ensure homogeneous mixing. Machine potting requires sufficient stirring speed, adjust as needed.
Uniform Potting: Manual operation should be done in small, multiple batches to ensure uniformity. Machine potting should follow the programmed path for quantitative dispensing.
Inspection or Secondary Potting: After potting, visually inspect as needed. Perform touch-up, bubble removal, or secondary potting if required.
Curing: Allow the potted and inspected products to cure at room temperature or with heat assistance (recommended 60°C if needed), according to product and process requirements.
Final Product Confirmation: Perform visual inspection and performance testing as required by the customer.
Hardener: Typically 20KG/ 200KG metal or plastic drums.
Resin: Typically 20KG / 200KG metal or plastic drums.
Store and transport as a general chemical product.
Store sealed, protected from light at room temperature. Shelf life varies from 6 to 12 months depending on packaging; please refer to the expiry date on the shipping package.
When temperature drops to 15°C or lower, the hardener or resin should be stored in a warm place or heated before use for potting. Specific heating recommendations depend on the temperature drop; please communicate and consult with us.
